Daikin VAM-FA - 2-6 Easy Installation and service maintenance; 2-7 Additional Optional accessories

• Heat reclaim ventilation • VAM-FA/FB
1
2
• Ventilation • Heat reclaim ventilation
8
2 Features
2 - 6 Easy Installation and service maintenance
Parallel air flow system (Daikin)Cross air flow system
This system prevents misconnection and simplify the installation work.
Service Maintenance
Upside-down installation is available.
It allows the common use of the access door and reduces the space and installation work.
For 2 units closely installed, only one inspection hole of 450 × 450 mm will do for maintenance or replacement of the heat exchanger element etc.
Long life filter is equipped.
2-7 Additional Optional accessories
Built-in optional high efficiency filter
It greatly reduces the installation space.
The installation of access doors and the unit can be reduced.
(HC0234) (HC0235)
SA
RA
EA
OA
SA
RA
EA
OA
(HC0235)
Switch Box
Maintenance cover
Access door
