• Heat reclaim ventilation • VAM-FA/FB
1
8
• Ventilation • Heat reclaim ventilation
20
8 Centre of gravity
8 - 1 Centre of Gravity
4D081262
VAM350-500FB
NOTES
1. The shown unit is VAM350FB
Design ref. AA AB AC
VAM350FB 24 51 10
VAM500FB 23 36 9
4D081263
VAM650-800FB
NOTES
1. The shown unit is VAM650FB
Design ref. AA AB AC
VAM650FB 20 42 6
VAM800FB 32 58 5
