3 Specifications
Standard Accessories : Installation and operation manual;
Fan Type Sirocco fan
Air flow rate - 50Hz
Heat
exchange
mode
Ultra
high
m³/h 150 250 350 500 650 800 1,000 1,500 2,000
High m³/h 150 250 -
Low m³/h 110 155 -
Bypass
mode
Ultra
high
m³/h 150 250 350 500 650 800 1,000 1,500 2,000
High m³/h 150 250 -
Low m³/h 110 155 -
Air flow rate - 60Hz
Heat
exchange
mode
Ultra
high
m³/h 150 250 -
High m³/h 150 250 -
Low m³/h 110 145 -
Bypass
mode
Ultra
high
m³/h 150 250 -
High m³/h 150 250 -
Low m³/h 110 145 -
External static
pressure - 50Hz
Ultra high Pa 69 64 98 93 137 157 137
High Pa 39 -
Low Pa 20 -
External static
pressure - 60Hz
Ultra high Pa 98 -
High Pa 54 -
Low Pa 24 20 -
Fan motor Quantity 2 4
Output 50 Hz W 30 80 106 210
60 Hz W 30 80 106 210
Sound pressure level -
50Hz
Heat exchange
mode
Ultra high dBA 27 / 28.5 28 / 29 32 33 34.5 36 39.5 40
High dBA 26 / 27.5 26 / 27 31.5 33 34.5 35 38
Low dBA 20.5 /
21.5
21 / 22 23.5 24.5 27 31 34 35
Bypass mode Ultra high dBA 27 / 28.5 28 / 29 32 33.5 34.5 36 40.5 40
High dBA 26.5 /
27.5
27 / 28 31 32.5 34 34.5 35.5 38
Low dBA 20.5 /
21.5
21 / 22 24.5 25.5 27 31 33.5 35
Sound pressure level -
60Hz
Heat exchange
mode
Ultra high dBA 28.5 29.5 34 34.5 35.5 37 41.5 42.5
High dBA 26.5 26 33 34 36 39 41
Low dBA 1919.52626.528 32 36 37
Bypass mode Ultra high dBA 28 29 34 34.5 35.5 37 41.5 42.5
High dBA 27 32.5 33.5 35 36 39 41
Low dBA 20 20.5 26.5 27.5 28.5 33 32 36 37
Operation range Min. ºCDB -15
Max. ºCDB 50
Relative humidity % 80% or less
On coil temperature Cooling Max. ºCDB -
Heating Min. ºCDB -
Connection duct diameter mm 100 150 200 250 350
Insulation material Self-extinguishable urethane foam
3-1 Technical Specifications
VAM150FA VAM250FA VAM350FB VAM500FB VAM650FB VAM800FB VAM1000FB VAM1500FB VAM2000FB
