• Ventilation • Heat reclaim ventilation
39
• Heat reclaim ventilation • VAM-FA/FB
12 Air filter characteristics
12 - 1 High efficiency filter / dust filter for VAM350-2000FB
12 - 1 - 1 - 3 Add up all the pressure drops of the duct system on the installation site and the filters
[For filter characteristics, refer to D-drawings]
NOTES
1 Table shows values at nominal level, refer to drawings for detailed information
2 Filters according to
3 For more information refer to VAM installation, operation manual or filter manual
To adjust static pressure after filter placement:
unit airflow (m³/h) filter pressure drop
M6 F7 F8
VAM350F 350
39 52 88
VAM500F 500
65 87 148
VAM650F 650
61 83 140
VAM800F 800
89 121 206
VAM1000F 1000
80 109 185
VAM1500F 1500
79 106 181
VAM2000F 2000
80 109 185
Setting mode Setting switch No. Description of setting
17 (27) 0 Filter cleaning time setting
19 (29)
2 SA fan speed setting
3 EA fan speed setting
