Daikin WGZ030DW - Introduction and Installation; Safety Warnings and Precautions

OMM 1130-2 5
Figure 2, Condenser Pressure Drop, WGZ030D – WGZ200D
Unit Model
Ref
#
Min. Flow & PD
Nom. Flow & PD
Max. Flow & PD
IP
SI
IP
SI
IP
SI
GPM
Ft.
L/S
kPa
GPM
Ft.
L/S
kPa
GPM
Ft.
L/S
kPa
WGZ030D
A
56.1 2.4
3.5 7.2
89.7 6.3
5.7 18.8
149.5 17.4
9.4 52.0
WGZ035D
B
64.9
3.4
4.1
10.2
103.8
8.6
6.5
25.7
173.0
23.9
10.9
71.4
WGZ040D
C
76.3
2.7
4.8
8.1
122.1
6.9
7.7
20.6
203.5
19.3
12.8
57.7
WGZ045D
D
85.3
3.6
5.4
10.8
136.5
9.2
8.6
27.5
227.5
25.7
14.4
76.8
WGZ050D
E
96.4
2.9
6.1
8.7
154.2
7.5
9.7
22.4
257.0
20.7
16.2
61.9
WGZ055D
F
105.8 3.8
6.7 11.4
169.2 9.7
10.7 29.0
282.0 26.8
17.8 80.1
WGZ060D
G
113.4
4.5
7.2
13.5
181.5
11.6
11.5
34.7
302.5
32.3
19.1
96.5
WGZ070D
H
132.8
4.1
8.4
12.3
212.4
10.4
13.4
31.1
354.0
29.0
22.3
86.7
WGZ080D
I
146.8
3.7
9.3
11.1
234.9
9.5
14.8
28.4
391.5
26.5
24.7
79.2
WGZ090D
J
165.0
3.4
10.4
10.2
264
8.8
16.7
26.3
440.0
24.5
27.8
73.2
WGZ100D
K
183.4 3.4 11.6 10.2 293.4 8.8 18.5 26.3 489.0 24.4 30.9 72.9
WGZ115D
L
211.7
4.8
13.4
14.3
338.7
12.3
21.4
36.8
564.5
34.1
35.6
101.9
WGZ130D
M
235.1
6.1
14.8
18.2
376.2
15.5
23.7
46.3
627.0
43.1
39.6
128.8
WGZ150D
N
274.9
6.2
17.3
18.5
439.8
15.8
27.7
47.2
733.0
43.8
46.2
130.9
WGZ170D
O
317.4
5.5
20.0
16.4
507.9
14.0
32.0
41.8
846.5
38.9
53.4
116.3
WGZ200D
P
352.7 7.4
22.3 22.1
564.3 18.8
35.6 56.2
940.5 52.3
59.3 156.3
Pressure Drop (ft of water)
Flow Rate (GPM)
