Daikin WGZ030DW - Parameter Details

OMM 1130-2 73
Tabl
e continued
Type
Index
I/O
Description
LONworks
BACnet
Modbus
I 11 O Active alarms 11
x
x
x
I 12 O Active alarms 12
x x x
I
13
O
Active alarms 13
x
x
x
I 14 O Active alarms 14
x x x
I
15
O
Active alarms 15
x
x
x
I 16 O Active alarms 16
x
x
x
I 17 I Network chiller mode set point
x x x
I
18
O
LON Chiller run mode
x
x
I
19
O
Active chiller mode
x
x
x
I
20
I
Network demand limit default set point
x
I 21 I Network chiller mode default set point
x
I 22 O
Sequence Status
Bit 1 – Unit Full Load Flag
Bit 2 – Circuit One Available Flag
Bit 3 – Circuit Two Available Flag
x x x
I
28
O
Unit model type, refrigerant
x
x
x
I
29
O
Unit language
x
x
x
I 30 O Unit software version
x x x
I 32 I Compressor select
x
x
x
I 35 I/O Clock year
x x
I
36
I/O
Clock month
x
x
I 37 I/O Clock day of month
x
x
I
38
I/O
Clock day of week
x
x
I 39 I/O Clock hours
x
x
I 40 I/O Clock minutes
x x
I
45
O
Compressor starts
x
x
I 46 O Compressor run hours
x
x
D 1 I/O Network chiller enable set point
x
x
x
D 2 O Chiller enable status
x x x
D
3
O
Active alarm indicator
x
x
x
D 4 O Chiller run enabled
x
x
x
D
5
O
Chiller local control
x
x
x
D 6 O Chiller capacity limited
x
x
x
D 7 O Evap flow
x x x
D
8
O
Cond flow
x
x
x
D
9
I
Network chiller enable default set point
x
D
10
I
Ignore network defaults
x
D 24 I Network clear alarm signal
x
x
x
Parameter Details
Units of Measure
Parameters will be expressed in different units dependant on the protocol selected.
Parameter
Type
Modbus
Units
BACnet
Units
LONworksU
nits
Temperature
o
F X 10
o
F X 10
o
C X 100
Pressure PSI X 10 PSI X 10 KPa X 10
Percentage % X 10 % X 10 % X 200
