30
9.6 Programming personalised voice messages for intrusion groups
9.7 Ethernet connection and programming (IP link)
Connection with partial unbundling
A single filter must be used to guarantee operation.
Connection with full unbundling
Programming Display Actions to be performed
to be performed
Recording Select the Programming menu using the L and M keys,
personalised voice then press OK
messages for
intrusion groups
Select the General menu using the L and M keys,
then press OK
Select the Recording mess. menu using the L and M keys,
then press OK
Select the group to be personalised using the L and M keys,
then press OK
N.B.: up to 8 groups depending on the control panel type.
Select Change to start recording the voice message (3 s max). Once the voice message
has been delivered, press OK to validate recording.
Install mode
Programming
Programming
General
General
Recording mess.
Recording mess.
Group 1
Group 1
Change
Ethernet programming (IP link)
To be able to operate behind an ADSL box/router, the dialler must have an IP address. There are two ways to allocate this IP address:
• Automatically (default programming): the parameters can be obtained from a DHCP server (dynamic IP address) in which case the
ADSL box/router allocates the address automatically.
N.B. if the dialler is unable to locate a DHCP server, the temporary address 192.168.0.197 is allocated. In this case, the dialler
cannot access the Digicom company and issues the error message “programming error” when switched to user mode.
Dialler
Unfiltered
output
RJ11
IP telephone
RJ45 network cable (IP)
