6 mm
2.5 mm
PH.1
2. Preparation
IMPORTANT: the fixing screws
and plugs are not provided.
1. Unclip the front panel
from the bottom.
2. Remove the front panel.
3. Loosen the 2 screws. 4. Remove the electronic part
from the base.
5. Remove the pre-cut part of the sticker and
stick it to the guarantee certificate inside
the user manual supplied with the control
panel. If you are adding to an existing
system, use the guarantee certificate
supplied with this product.
6. Connect the lithium power pack to its support.
