8 Spyder2 4k User’s Manual
03-032-10195-04 DALSA
Specification Units Min Max Notes
Temperature
Front plate Temperature °C 10 50 1
Temperature drift before
recalibration, (recommendation)
°C 10
Sensor Alignment
x,y µm ±175
z mm ±0.18
θz
° ±0.6
Note that the environment conditions represent the state of the environment when the
camera was being tested. Typical results are the average values obtained with at a 1 kHz
line rate and 30 °C. Maximum results represent the worst case results from any camera
operating at 50 °C with a 1 kHz line rate.
Table 2. Spyder2 4k Performance Specifications, 1 kHz line rate
Min. Gain Nom. Gain Max. Gain
Environment
Conditions
Units Min Typ Max Min Typ Max Min Typ Max Notes
Data Rate MHz 40 40 40 40 40 40 40 40 40
Line Rate kHz 1 1 1 1 1 1
Gain Setting dB -10 -10 -10 0 0 0 +10 +10 +10
Front Plate
Temperature
°C 30 50 30 50 30 50 1
Electro-Optic
Specifications
Units Min Typ Max Min Typ Max Min Typ Max Notes
Broadband
Responsivity
DN/(nJ/cm
2
) 6 6.8 7.6 18.8 21.4 24 60 68 76
Dynamic Range Ratio 496:1 207:1 390:1 62:1 135:1
RMS Noise, max DN 0.5 0.5 0.75 1.2 2.2 4 3
FPN uncorrected, max DN 1.1 4 3.5 8 8 27 4
FPN corrected, max DN 0.3 2 1 2 2 8 2
PRNU uncorrected
ECD/ECE
DN 9 28 10 28 12/20 43
PRNU corrected
ECD/ECE
DN 1.5/ 2 3/3 1.2/.5 3/8 2/3.5 8/27 2
DC Offset DN 5 5
Notes:
DN = Digital Numbers (0-255); also known as gray levels.
ECE = Exposure Control Enabled
ECD = Exposure Control Disabled
• All measurements taken in 8 bit output mode.
• All measurements are valid for front plate temperatures in still air.
• All measurements used a Tungsten halogen light source, 3200 K bulb temp., and 750
nm cutoff filter
