Marine application 3.14.2
Figure 15. Example of Unit Control Panel for Marine applications
A functional description of buttons, lamps and switches placed on the unit control panel is presented
below. Please note that this is a description of unit control panel including all options, and your
SEM-SAFE
®
High-Pressure Water Mist Pump Unit might not contain all of them.
Button/Lamp/Switch
Description
System ready
Lamp is turned on when the SEM-SAFE
®
High-Pressure Water Mist
Pump Unit is ready to run. It indicates normal stand-by operation
when supply is turned on.
Main power
Button for manual start of main supply. Should be used if
lamp ‘System ready’ is not turned on.
Control power
Controlling if circuits in UCP are working properly. If lamp is on, it
means that control of circuits is turned on. If it is off, system is not
ready to run (System ready lamp is off).
