Danfoss Semco SEM-SAFE - FM Global Unit Control Panel

PAGE 32 / 48
END USER MANUAL
OPERATION AND MAINTENANCE OF HIGH PRESSURE WATER MIST PUMP UNIT
REVISION 4, MAY 2016
Low level in unit tank
System activated
Emergency stop activated
Wire break error on system pressure transmitter,
pressure switch, main and test valve
Note:
Refer to the DIOMA (Design Installation Operation Maintenance Approval) manual for your
system received from Danfoss Semco A/S to see a complete list of alarms, their meaning and ways
to solve the problem.
FM Global Unit Control Panel 3.14.4
The FM Global SEM-SAFE
®
High-Pressure Water Mist Pump Unit is designed differently to all
other pump units produced by Danfoss Semco A/S. It has a separate Unit Control Panel for each
high-pressure pump. Please see example of the complete FM Global SEM-SAFE
®
High-Pressure
Water Mist Pump Unit below.
Figure 19. FM Global High-Pressure Pump Unit with 4 HP pumps
