1.1Importantsafetyandproductinformation

1.1.1Importantsafetyandproductinformation

ThisInstallationGuideisassociatedwithECLApplicationKeyA275

(ordercodeno.087H3814).

TheECLKeyA275containstwosetsofapplications:onesetfor

A275(A275.1/A275.2/A275.3)andanothersetforA375(A375.1

/A375.2/A375.3).

TheapplicationsA275arefor1-burnersolutions.

TheapplicationsA375areformultipleburnersolutions.

Thefunctionscanberealizedin:

ECLComfort210(A275)forsimplesolutionsor

ECLComfort310(A275/A375)foradvancedsolutions,e.g.M-bus,

ModbusandEthernet(Internet)communication.

TheapplicationA275complieswithECLComfortcontroller210

and310asofsoftwareversion1.11(visibleatstart-upofthe

controllerandin‘Commoncontrollersettings’in‘System’).

AdditionaldocumentationforECLComfort210andaccessoriesis

availableonwww.ecl.doc.danfoss.com.

A275/A375navigationingeneral:

A275.1/A375.1A275.2/A375.2A275.3/A375.3

CircuitCircuitCircuit

Burnercontroloverview:

R2–R10=relaynos.inECL/ECA32

Seethesection‘Electricalconnections’formoredetailedinformation.

Applicationkeysmightbereleasedbeforealldisplaytextsare

translated.InthiscasethetextisinEnglish.

VI.GU.L2.02

OperatingGuideECLComfort210/296/310,applicationA275/A375
