5VI.UH.Q1.52
Produced by Danfoss Floor Heating Hydronics 08.2008
Instruction CF-RD Room Thermostat with Display
Note:
• To activate batteries in the Room Thermostat
please remove enclosed strips from the batteries.
• The assignment of the Room Thermostats to the
Master Controller should be within 1½m distance
Activate Install mode on
Master Controller - g. 1.
• Use the menu selection button
to select the
Install mode. Install LED ashes
• Activate Install mode by pressing OK . Install
LED goes ON
Activate Install mode on
Room Thermostat
• Press the push button . LED and icker
during communication
Select output on Master Controller
• All available output LEDs on Master Controller
light up, and the rst of them ashes
• Press output selection button , select desired
output (ashes) and accept with OK
• All output LEDs go OFF. Selected output
stays ON shortly
2. Installation
