AK-CC550 Manual RS8EN502 © Danfoss 02-2010 29
Pumpdowndelay
d16 1 1 1 1 1 1 1 1 1 1 0 min. 60min. 0
Draindelay(usedathotgasdefrostonly) d17 1 0 min. 60min. 0
Max. aggregate refrigeration time between two defrosts
d18 1 1 1 1 1 1 1 1 1 1 0 hrs 48hrs 0/OFF
Heatindriptray.Timefromdefrostingstopstoheating
inthedriptrayisswitchedo
d20 1 0 min. 240min. 30
Extradefrostwithadaptivefunctionallowed:
0=none,1=monitoringonly,2=Dayonly,3=Bothday
andnight,4=Nightonly
d21 1 1 1 1 1 1 1 1 1 1 0 4 0
Resetofthe"Adaptivedefrostingfunction"(startsa
defrostandstartssubsequentnewtuning)
d22 1 1 1 1 1 1 1 1 1 1 0/OFF 1/ON 0/OFF
Injection control function
Injectionalgorithm
Onlyfortrainedpersonnel
n05 1 1 1 1 1 1 1 1 1 1 30sec 600sec 150
Max.valueofsuperheatreference
n09 1 1 1 1 1 1 1 1 1 1 3°C 20°C 12
Min.valueofsuperheatreference
n10 1 1 1 1 1 1 1 1 1 1 3°C 20°C 3
MOPtemperature.OifMOPtemp.=15.0°C n11 1 1 1 1 1 1 1 1 1 1 -50°C 15°C 15
GlideforEzotroperefrigerant(atS1-measurementonly) n12 1 1 1 1 1 1 1 1 1 1 0 K 10 K 0
PeriodtimeofAKVpulsation
Onlyfortrainedpersonnel
n13 1 1 1 1 1 1 1 1 1 1 3sec 6sec 6
Injectionalgorithm
Onlyfortrainedpersonnel
n15 1 1 1 1 1 1 1 1 1 1 30sec 600sec 180
Injectionalgorithm
Onlyfortrainedpersonnel
n16 1 1 1 1 1 1 1 1 1 1 10% 75% 30
Injectionalgorithm
Onlyfortrainedpersonnel
n17 1 1 1 1 1 1 1 1 1 1 5% 70% 30
Injectionalgorithm
Onlyfortrainedpersonnel
n18 1 1 1 1 1 1 1 1 1 1 0 10 4
Injectionalgorithm
Onlyfortrainedpersonnel
n23 1 1 1 1 1 1 1 1 1 1 1 50 6
Injectionalgorithm
Onlyfortrainedpersonnel
n24 1 1 1 1 1 1 1 1 1 1 100 sec 1800 sec 900
Selection of signal to superheat measurement: 1=
pressuretransmitterAKS32R,2=TemperaturesensorS1
n57 1 1 1 1 1 1 1 1 1 1 1 2 1
Fan
Fanstoptemperature(S5)
F04 1 1 1 1 1 1 1 1 1 1 -50°C 50°C 50
Pulseoperationonfans:0=Nopulseoperation,1=At
thermostatcutsoutonly,2=Onlyatthermostatcut
outs during night operation
F05 1 1 1 1 1 1 1 1 1 1 0 2 0
Periodtimeforfanpulsation(on-time+o-time) F06 1 1 1 1 1 1 1 1 1 1 1 min. 30min. 5
On-timein%ofperiodtime F07 1 1 1 1 1 1 1 1 1 1 0% 100% 100
Real time clock
Six start times for defrost.
Setting of hours.
0=OFF
t01 -
t06
1 1 1 1 1 1 1 1 1 1 0 hrs 23hrs 0
Six start times for defrost.
Setting of minutes.
0=OFF
t11 -
t16
1 1 1 1 1 1 1 1 1 1 0 min. 59min. 0
Clock-Settingofhours
t07 1 1 1 1 1 1 1 1 1 1 0 hrs 23hrs 0
Clock-Settingofminute
t08 1 1 1 1 1 1 1 1 1 1 0 min. 59min. 0
Clock-Settingofdate
t45 1 1 1 1 1 1 1 1 1 1 1 day 31day 1
Clock-Settingofmonth
t46 1 1 1 1 1 1 1 1 1 1 1 mon. 12 mon. 1
Clock-Settingofyear
t47 1 1 1 1 1 1 1 1 1 1 0 year 99year 0
Miscellaneous
Delay of output signals after start-up
o01 1 1 1 1 1 1 1 1 1 1 0 sec 600sec 5
InputsignalonDI1.Function:
0=notused.1=statusonDI1.2=doorfunctionwithalarm
whenopen.3=dooralarmwhenopen.4=defroststart
(pulse-signal).5=ext.mainswitch.6=nightoperation
7=thermostatbandchangeover(activater21).8=alarm
functionwhenclosed.9=alarmfunctionwhenopen.
10=casecleaning(pulsesignal).11=forcedcoolingathot
gas defrost, 12=nightcover
o02 1 1 1 1 1 1 1 1 1 1 0 12 0
Networkaddress
o03 1 1 1 1 1 1 1 1 1 1 0 240 0
On/Oswitch(ServicePinmessage)
IMPORTANT!o61mustbesetpriortoo04
(usedatLON485only)
o04 1 1 1 1 1 1 1 1 1 1 0/O 1/On 0/O
Accesscode1(allsettings)
o05 1 1 1 1 1 1 1 1 1 1 0 100 0
Usedsensortype:0=Pt1000,1=Ptc1000, o06 1 1 1 1 1 1 1 1 1 1 0/Pt 1/Ptc 0/Pt
Max hold time after coordinated defrost
o16 1 1 1 1 1 1 1 1 1 1 0 min. 360min. 20
Selectsignalfordisplayview.S4%(100%=S4,0%=S3)
o17 1 1 1 1 1 1 1 1 0% 100% 100
Pressuretransmitterworkingrange–min.value
o20 1 1 1 1 1 1 1 1 1 1 -1 bar 5 bar -1
Pressuretransmitterworkingrange–max.value
o21 1 1 1 1 1 1 1 1 1 1 6bar 200 bar 12
Continued Code 1 2 3 4 5 6 7 8 9 10 Min. Max. Fac. Actual
