3. Mounting and wiring
This section describes how the controller:
• Is fitted
• Is connected
We have decided to work on the basis of the example we went
through previously, i.e. the following modules:
• AK-PC 781A controller module
• AK-XM 205A input and output module
• AK-XM 208C analog input module + stepper output module
• AK-XM 102B digital input module
• AK-XM 103B analog input and output module
• AK-OB 110 analog output module
