84 Capacity controller RS8HE202 © Danfoss 2017-07 AK-PC 781A
7. Move on through all the individual displays for the
condenser group.
Change displays with the +- button. Remember the settings at
the bottom of the pages – the ones that can only be seen via
the ”Scroll bar”.
8. Safety limits
9. Go back to the overview and move on to the rest of
the functions.
10. General functions
When all the functions in overview display 1 have been re-
viewed, it is time to look at the "General functions" in overview
display 2. Press the + button to access.
The first is the thermostat group
Check the settings.
11. Then the pressure switch group
Check the settings.
12. Proceed with the remaining functions.
13. The controller setup has been completed.
Check of settings - continued
The last page contains safety limits and restart times.
All the defined general functions are shown in overview display 2.
In addition to always being shown in display 2, functions can be
selected to be shown in display 1. Individual functions can be selected
for display in display 1 via the "Show in overview display" setting.
