AKD 2800
■ Display readout
Fr
The frequency converter shows the present
output frequency in Hertz [Hz].
Io
The frequency converter shows the present
output current in Amps [A].
Uo
The frequency converter shows the present
output voltage in Volt [V].
Ud
The frequency converter shows the intermediate
circuit voltage in Volt [V].
Po
The frequency converter shows the calculated
output in kilowatt [kW].
notrun
This message is shown if an attempt is made to change
a parameter value while the motor is running. Stop
the motor to change the parameter value.
■ Warnings/alarm messages
A warning or an alarm will appear in the display
as a numerical code Err. xx. A warning will
be shown on the display until the fault has
been corrected, while an alarm will continue to
flash until the [STOP/RESET] key is activated.
The table shows the various warnings and alarms, and
whether the fault locks the frequency converter. After a
Trip locked the mains supply is cut off and the fault is
corrected. The mains supply is reconnected and the
frequency converter is reset. The frequency converter is
now ready. A Trip can be reset manually in three ways:
1. Via the operating key [STOP/RESET].
2. Via a digital input.
3. Via serial communication.
It is also possible to choose an automatic reset in
parameter 405 Reset function. When a cross appears
in both warning and alarm, this can mean that a
warning comes before an alarm. It can also mean
that it is possible for the user to programme whether
a warning or an alarm will appear for a given fault.
For example, this is possible in parameter 128 Motor
thermal protection. After a trip the motor will coast,
and alarm and warning will blink on the frequency
converter, but if the fault disappears only the alarm
will blink. After a reset the frequency converter
will be ready to start operation again.
No. Description Warning Alarm Trip
locked
2Livezeroerror(LIVEZEROERROR) X X X
4 Mains phase loss (MAINS PHASE LOSS) X X X
5 Voltage warning high (DC LINK VOLTAGE HIGH) X
6 Voltage warning low (DC LINK VOLTAGE LOW) X
7 Overvoltage (DC LINK OVERVOLT) X X X
8 Undervoltage (DC LINK UNDERVOLT) X X X
9 Inverter overload (INVERTER TIME) X X
10 Motor overloaded ( MOTOR, TIME) X X
11 Motor thermistor (MOTOR THERMISTOR) X X
12 Current limit (CURRENT LIMIT) X X
13 Overcurrent (OVERCURRENT) X X X
14 Earth fault (EARTH FAULT) X X
15 Switch mode fault (SWITCH MODE FAULT) X X
16 Short-circuit (CURR. SHORT CIRCUIT) X X
17 Serial communication timeout (STD BUS TIMEOUT) X X
33 Out of frequency range (OUT FREQ RNG/ROT LIM) X
35 Inrush fault (INRUSH FAULT) X X
36 Overtemperature (OVERTEMPERATURE) X X
37-45 Internal fault (INTERNAL FAULT) X X
50 AMT not possible X
51 AMT fault re. nameplate data (AMT TYPE.DATA FAULT) X
54 AMTwrongmotor(AMTWRONGMOTOR) X
55 AMT timeout (AMT TIMEOUT) X
56 AMT warning during AMT (AMT WARN. DURING AMT) X
99 Locked (LOCKED) X
MG.28.H2.02 -
58
