PNU
#
Parameter
description
Factory setting 4-setup Conv.
index
Data
type
201 Output frequency,
low limit f
MIN
30 Hz Yes -1 6
202 Output frequency,
high limit f
MAX
60 Hz Yes -1 6
204 Minimum ref Ref
MIN
30 Hz Yes -3 4
205 Maximum ref Ref
MAX
60 Hz Yes -3 4
207 Ramp-up time 1 0.70 sec. Yes -2 7
208 Ramp-down time 1 1.00 sec. Yes -2 7
214 Reference function Sum Yes 0 5
215 Preset reference 1 0.00% Yes -2 3
216 Preset reference 2 0.00% Yes -2 3
217 Preset reference 3 0.00% Yes -2 3
218 Preset reference 4 0.00% Yes -2 3
224 Warn. High current I
MAX
Yes -1 6
225 Warn. Low frequency 0.0 Hz Yes -1 6
226 Warn. High frequency 132.0 Hz Yes -1 6
227 Warn. Low Feedback -4000.000 Yes -3 4
228 Warn. High Feedback 4000.000 Yes -3 4
229 Frequency bypass,
bandwidth
0Hz(OFF) Yes 0 6
230 Frequency bypass 1 0.0 Hz Yes -1 6
231 Frequency bypass 2 0.0 Hz Yes -1 6
PNU
#
Parameter
description
Factory setting 4-setup Conv.
index
Data
type
302 Digital input, term. 18 Start Yes 0 5
303 Digital input, term. 19 Reversing Yes 0 5
304 Digital input, term. 27 Reset and coast inverse Yes 0 5
305 Digital input, term. 29 Jog Yes 0 5
307 Digital input, term. 33 No function Yes 0 5
308 Term. 53, analogue input voltage Reference Yes 0 5
309 Term. 53, min scaling 0.0 V Yes -1 6
310 Term. 53, max scaling 10.0 V Yes -1 6
314 Term. 60, analogue input current No function Yes 0 5
315 Term. 60, min scaling 0.0 mA Yes -1 6
316 Term. 60, max scaling 20.0 mA Yes -1 6
317 Time out 10 sec. Yes 0 5
318 Function after timeout Nofunction Yes 0 5
319 Term. 42, analogue output 0-I
MAX
=0-20mA Yes 0 5
4-Setup:
’Yes’ means that the parameter can be programmed
individually in each of the four Setups, i.e. one single
parameter can have four different data values. No’
meansthatthedatavaluewillbethesameinallSetups.
C
onversion index:
This number r
efers to a conversion figure to be used
when writing or reading via serial communication
with a frequency converter.
See Data cha
racter in Serial communication.
D
ata type:
Data type shows the type and length of the telegram.
Data type Description
3 Integer 16
4 Integer 32
5 Unsigned 8
6 Unsigned 16
7 Unsigned 32
9Textstring
MG.28.H2.02 -
73
