AKD 2800
PNU
#
Parameter-
description
Factory setting 4-setup Conv.
index
Data-
type
100 Configuration Speed reg., open loop Yes 0 5
101 Torque characteristics Constant torque Yes 0 5
102 Motor power P
M,N
depends on unit Yes 1 6
103 Motor voltage U
M,N
depends on unit Yes 0 6
104 Motor frequency f
M,N
50 Hz Yes -1 6
105 Motor current I
M,N
depends on motor selected Yes -2 7
106 Rated motor speed depends on par. 102 Yes 0 6
107 Automatic motor adjustment Optimisation off Yes 0 5
108 Stator resistance R
S
depends on motor selected Yes -3 7
109 Stator reactance X
S
depends on motor selected Yes -2 7
122 Function at stop Coast Yes 0 5
126 DC braking time 10 sec. Yes -1 6
127 DC brake engaging frequency OFF Yes -2 6
128 Thermal motor protection No protection Yes 0 5
132 DC brake voltage 0% Yes 0 5
133 Start voltage depends on unit Yes -2 6
134 Load compensation 100% Yes -1 6
136 Slip compensation 100% Yes -1 3
137 DC hold voltage 0% Yes 0 5
MG.28.H2.02 -
72
