Danfoss AKD 2800 User Manual

AKD 2800
PNU
#
Parameter
description
Factory setting 4-setup Conv.
index
Data
type
405 Reset function Manual reset Yes 0 5
406 Aut. restart time 5 sec. Yes 0 5
412 Var. carrier frequency No LC-filter Yes 0 5
414 Min. feedback 0.000 Yes -3 4
415 Max. feedback 1500.000 Yes -3 4
416 Process units bar Yes 0
´
5
423 U1 voltage par. 103 Yes -1 6
424 F1 frequency Par. 104 Yes -1 6
425 U2 voltage par. 103 Yes -1 6
426 F2 frequency par. 104 Yes -1 6
427 U3 voltage par. 103 Yes -1 6
428 F3 frequency par. 104 Yes -1 6
437 Proc. PID no/inv. Normal Yes 0 5
438 Proc. PID anti wind. Active Yes 0 5
439 Proc. PID start frequency Par. 201 Yes -1 6
440 Proc. PID start proportional ampl. 0.01 Yes -2 6
441 Proc. PID integration time Off (9999.99) Yes -2 7
444 Proc. PID lowpass filter time 0.02 s Yes -2 6
PNU
#
Parameter
description
Factory setting 4-setup Conv.
index
Data
type
500 Address 1 No 0 5
507 Selection of Setup Logic or Yes 0 5
513 Bus time interval 1 sec. Yes 0 5
514 Bus time interval function Off Yes 0 5
515 Data readout: Reference % No -1 3
516 Data readout: Reference [unit] No -3 4
517 Data readout: Feedback [unit] No -3 4
518 Data readout: Frequency No -1 3
520 Data readout: Motor current No -2 7
522 Data readout: Power [kW] No 1 7
523 Data readout: Power [HP] No -2 7
524 Data readout: Motor voltage [V] No -1 6
525 Data readout: DC Link voltage No 0 6
526 Data readout: Motor thermal load No 0 5
527 Data readout: Inverter thermal load No 0 5
528 Data readout: Digital input No 0 5
529 Data readout: Analogue input, term. 53 No -1 5
531 Data readout: Analogue input, term. 60 No -4 5
533 Data readout: External reference No -1 6
534 Data readout: Status word No 0 6
537 Data readout: Inverter temperature No 0 5
538 Data readout: Alarm word No 0 7
539 Data readout: Control word No 0 6
540 Data readout: Warning word No 0 7
541 Data readout: Extended status word No 0 7
MG.28.H2.02 -
74
