Danfoss D9h Service Guide

9
7
8
4
3
10
2
6
5
1
130BF860.10
1 LCP (local control panel) 6 Nut (13 mm)
2 LCP cradle 7 Top fan (IP20)
3 Control terminals 8 Screw (T25)
4 Nut (10 mm) 9 Control card mounting plate
5 AC input busbars 10 Screw (T20)
Illustration 10.5 AC Input Busbars and Power Terminals
D1h/D3h/D5h/D6h/J8 Drive Di... Service Guide
MG94A502 Danfoss A/S © 02/2019 All rights reserved. 137
10 10

Danfoss D9h Specifications

General

Brand	Danfoss
Model	D9h
Category	DC Drives
Language	English
