Danfoss D9h Service Guide

11.2.11 Power Terminal Mounting Plate
To remove or reinstall the power terminal mounting plate, use the following steps. Refer to Illustration 11.4 and
Illustration 11.6.
Disassembly
1. Remove the motor terminal block. Refer to
chapter 11.2.9 Motor Terminal Block.
2. Remove 5 thread-forming screws (T25) from the
power terminal mounting plate.
3. Remove 3 nuts (8 mm) from the bottom of the
power terminal mounting plate.
4. Remove the power terminal mounting plate from
the unit.
Reassembly
Tighten fasteners according to chapter 14.1 Fastener Torque
Ratings.
1. Position the power terminal mounting plate in
the unit.
2. Secure 5 thread-forming screws (T25) in the
power terminal mounting plate.
3. Fasten 3 nuts (8 mm) at the bottom of the plate.
4. Replace the motor terminal block. Refer to
chapter 11.2.9 Motor Terminal Block.
D2h/D4h/D7h/D8h/J9 Unit Dis...
VLT
®
FC Series, D1h–D8h, Da2/Db2/Da4/Db4, E1h–E4h, J8/J9
200 Danfoss A/S © 02/2019 All rights reserved. MG94A502
