Danfoss D9h Service Guide

5
3
2
1
4
130BF849.10
1 Thread-forming screws (T20) 4 Thread-forming screw (T25)
2 Snubber capacitor 5 Screws (T25)
3 Screws (T30) – –
Illustration 10.11 Brake IGBT Module
D1h/D3h/D5h/D6h/J8 Drive Di... Service Guide
MG94A502 Danfoss A/S © 02/2019 All rights reserved. 153
