Page #191 background imageLoading...
Page #191 background image
1
5
6
4
3
2
130BF855.10
1 LCP 4 Control card mounting plate
2 LCP cradle 5 Top fan
3 Control terminals 6 Screw (T25)
Illustration 11.1 Control Card and Control Card Mounting Plate
D2h/D4h/D7h/D8h/J9 Unit Dis... Service Guide
MG94A502 Danfoss A/S © 02/2019 All rights reserved. 189
11 11
