Danfoss D9h Service Guide

1
130BF840.10
6
2
5
4
3
8
7
1 Top horizontal brake busbar 5 Bottom horizontal brake busbar
2 Screw (T40) 6 Middle horizontal brake busbar
3 Thread-forming screw (T25) (behind snubber capacitor) 7 Nut (13 mm)
4 Snubber capacitor 8 Vertical brake busbars
Illustration 13.33 Horizontal Brake Busbars in E2h/E4h Drives
E1h–E4h Drive Disassembly a...
VLT
®
FC Series, D1h–D8h, Da2/Db2/Da4/Db4, E1h–E4h, J8/J9
316 Danfoss A/S © 02/2019 All rights reserved. MG94A502
