Danfoss D9h Service Guide

130BX138.11
Frequency
converter
AC Line
Motor cable
Motor
Stray capacitance Stray capacitance
Ground Potential 1
Potential 2 Potential 3
Illustration 7.2 Ground Currents
AC line
Frequency
converter
Motor cable
Motor
Stray capacitance
130BX139.12
Signal wiring to BMS
Illustration 7.3 Signal Conductor Currents
Drive and Motor Application... Service Guide
MG94A502 Danfoss A/S © 02/2019 All rights reserved. 85
7 7
