FC 300 Design Guide
How to Program
16-53 Digi Pot Reference
Range:
0.0 - 0.0
*
0.0
Function:
The contribution of the Digital Potentiometer
to the a ctual referen ce.
" 16-6* Inputs and Outputs
16-60 Digital Input
Range:
0-0
*
0
Function:
Returns the signal states from the active digital
inputs. Input 18 corresponds to the bit at the far
left. "0" = no signal, "1" = connected sig n al.
16-61 Terminal53SwitchSetting
Option:
Current [0]
Voltage [1]
Function:
Returns the setting of input terminal 53.
Current=0;Voltage=1.
16-62 Ana log Input 53
Range:
0.000 - 0.000
*
0.000
Function:
Returns the actual value on input 53 either as
reference or protection value.
16-63 Terminal54SwitchSetting
Option:
Current [0]
Voltage [1]
Function:
Returns the setting of input terminal 54.
Current=0;Voltage=1.
16-64 Ana log Input 54
Range:
0.000 - 0.000
*
0.000
Function:
Returns the actual value on input 54 either as
reference or protection value.
16-65 Analog Output 42 [mA]
Range:
0.000 - 0.000
*
0.000
Function:
Returns the actual value in mA on output 42.
Select the shown value in par. 06-50.
16-66 Digital Output [bin]
Range:
0-0
*
0
Function:
Returns the bin value of all digital outputs.
16-67 Freq. Input #29 [Hz]
Range:
0-0
*
0
Function:
Returns the actua l frequency rate on t erminal 29.
16-68 Freq. Input #33 [Hz]
Range:
0-0
*
0
Function:
Returns the actual value of the frequency applied
on terminal 29 as a n impulse input.
16-69 Pulse Output #27 [Hz]
Range:
0-0
*
0
Function:
Returns the actual value of impulses applied to
terminal 27 in digital output mode.
16-70 Pulse Output #29 [Hz]
Range:
0-0
*
0
Function:
Returns the actual value of impulses applied to
terminal 29 in digital output mode.
*
default setting ()display text []value for use in communication via serial communication port
217
MG.33.B
3.22 - VLT is a registered Danfoss trademark
