Danfoss D9h Design Guide

FC 300 Design Guide
How to Select Your VLT
" Ordering Numbers: Brake Resistors,
380-500 VAC
Standard brake resistors
10% duty cycle 40% duty cycle
FC 301/ FC 302
Resistance,
[ohm]
Power, [HP,
kW]
Code No. Resistance,
[ohm]
Power, [HP,
kW]
Code No.
PK37 620 0.065 175U1840 620 0.260 175U1940
PK55
620 0.065 175U1840 620 0.260 175U1940
PK75 620 0.065 175U1840 620 0.260 175U1940
P1K1
425 0.095 175U1841 425 0.430 175U1941
P1K5 310 0.250 175U1842 310 0.80 175U1942
P2K2
210 0.285 175U1843 210 1.35 175U1943
P3K0 150 0.430 175U1844 150 2.0 175U1944
P4K0
110 0.60 175U1845 110 2.4 175U1945
P5K5 80 0.85 175U1846 80 3. 0 175U1946
P7K5
65 1.0 175U1847 65 4.5 175U1947
1. Order 2 pieces.
Ordering Numbers: B
rake Resistors, 380-500 VAC
Flatpack brake resistors
FC 301/ FC 302 Motor [HP,
kW]
Resistor, [ohm] Size Order number Max. duty cycle, [%]
PK37 - - 620 Ω 100 W 175U1001 -
PK55 - - 620 Ω 100 W 175U1001 -
PK75 0.75 630 620 Ω 100 W 175U1001 14.0
PK75 0.75 630 620 Ω 200 W 175U0982 40.0
P1K1 1.1 430 430 Ω 100 W 175U1002 8.0
P1K1 1.1 430 430 Ω 200 W 175U0983 20.0
P1K5 1.5 320 310 Ω 200 W 175U0984 16.0
P2K2 2.2 215 210 Ω 200 W 175U0987 9.0
P3K0 3 150 150 Ω 200 W 175U0989 5.5
P3K0 3 150 300 Ω 200 W 2 x 175U0985
1
12.0
P5K5 4 120 240 Ω 200 W 2 x 175U0986
1
11.0
P5K5 5.5 82 160 Ω 200 W 2 x 175U0988
1
6.5
P7K5 7.5 65 130 Ω 200 W 2 x 175U0990
1
4.0
1. Order 2 pieces.
Mounting angle for flatpack resistor 100 W 175U0011
Mounting angle for flatpack resistor 200 W 175U0009
72
MG.33.B3.22 - VLT is a registered Danfoss trademark
