Video
Video output
Description Unit Minimum Maximum Typical Comment
Short circuit protection V 0 36 — —
12 V output voltage
(9 V < Ubat < 70 V)
V 11.5 12.5 12 —
12 V output current A — — 0.5 Vbus < 5.25 V
24 V output voltage
(9 V < Ubat < 70 V)
V 23 24 24 —
24 V output current A — 0.5 — —
Video inputs — — — — Both NTSC and PAL support
To power the camera up, it is recommended to use the display as power supply. If using a different power
supply, it should meet the specification of the camera in regards of the voltage type and range, the
current and voltage amount it can supply to its load, stability of the output voltage and current under
varying line and load conditions, operating/storage temperature ranges.
The use of a different power supply for the camera can create “noise” on the signal line which will affect
its functionality.
Real Time Clock (RTC)
Parameter Min Max Units
Backup Time 1 month
Drift 10 s/day
Technical Information
DP7XX Series Displays
Inputs/outputs
14 |
©
Danfoss | November 2016 L1315553 | BC00000223en-US0504
