Electrical
Supply voltage
Description Unit Minimum Maximum Comment
DC supply voltage V 9 36 With reverse polarity protection
DC supply current (circuit board only) A 0 1 UBat = 14 V
0 0.5 UBat = 28 V
Power supply interruption
(without rebooting)
ms — — 200 ms
5 V reference output
Description Unit Minimum Maximum
Output voltage V 4.8 5.2
Output current A 0 0.5
Output short circuit A — 1
Short circuit protection V 0 36
Measuring of output voltage V 0 5.75
Resolution mV 1.4
Worst case error mV ± (20+U*2%)
Warning
Output pins produce high voltage. High voltage can cause fire and/or electrical shock, if flammable
gasses or chemicals are present, can cause an explosion. To protect against product damage and possible
injury, do not exceed power supply voltage ratings and do not store this product where flammable
gasses or chemicals are present.
Environmental
Temperature
Description Units Minimum Maximum Comment
Operating temperature ˚C [˚F] -30 [-22] +60 [+140] —
Storage temperature ˚C [˚F] -30 [-22] +80 [+176] —
Ingress Protection (IP) rating
Series Rating Comment
DP700, DP710, DP720 IP67
With mating connector installed and sealing plugs in
unused connections.
DP730 Front: IP69K
Rear: IP67
Warning
Excessive high/low operating/storage temperatures can damage electronics. Damaged electronics can
result in performance failure. To protect against product damage and possible injury, do not operate/
store product in a environment that exceeds specified temperature ratings.
Technical Information
DP7XX Series Displays
Product ratings
18 |
©
Danfoss | November 2016 L1315553 | BC00000223en-US0504
