Page #17 background imageLoading...
Page #17 background image
32 VI.KT.G2.02 © Danfoss 05/2007 DH-SMT/DK
DH-SMT/DK VI.KT.G2.02 © Danfoss 05/2007 33
Knee point 7162
Setting range Factory setting
OFF / 30 ... 50 °C 40 °C
Choose the temperature at which the heat curve should bend.
OFF: Floor heating systems.
30 ... 50:
Radiator systems.
Min. on time (min. activation time gear motor) 7189
Setting range Factory setting
2 ... 50 10
The min. pulse length in milliseconds for activation of the gear motor.
Setting Value x 20 ms
2 40 ms
10 200 ms
50 1000 ms
The setting should be kept as high as acceptable to increase the lifetime of the actuator.
Daylight (daylight saving time changeover) 7198
Setting range Factory setting
ON / OFF ON
Choose whether you want the change to summer / winter time to be automatic or manual.
ON: The controller’s built-in clock automatically changes + / - one hour on
the standardized days for daylight saving time changeover for Central
Europe.
OFF: You change manually between summer and winter time by setting the
clock backward or forward.
ECL address (master / slave address) 7199
Setting range Factory setting
0 ... 15 15
This settting is relevant if more controllers are working in the same ECL Comfort system (connected via
the ECL BUS) and / or ECA units are connected.
0: The controller works as slave. The slave receives information about the
outdoor temperature (S1), system time, and signal for DHW demand in
the master.
1 ... 9: The controller works as slave. The slave receives information about the
outdoor temperature (S1), system time, and signal for DHW demand
in the master. The slave sends information about the desired flow
temperature to the master.
10 ... 14:
Not used.
15: The controller is master. The master sends information about the outdoor
temperature (S1) and system time. The ECL BUS is active and connected
ECAs are powered.
The ECL Comfort controllers can be connected via the ECL BUS to perform a larger
system. The controller, which is physically connected with the outdoor temperature
sensor, is the master of the entire system and must have the address 15.
Each slave must be configured with its own address (1 ... 9).
However, more slaves can have the address 0 if they only have to receive information
about outdoor temperature and system time.
Type 7600
Setting range Factory setting
116 / 130 130
Use this setting to change your application or restore the factory settings.
116: Constant temperature control of DHW circuit.
130: Weather compensated control of heating and boiler systems.
5 sec.
Start the chosen application.
Factory settings are restored. All personal settings will be deleted. It is recommended to
make a note of your personal settings in the ‘Settings overview’ for future use.
