Danfoss ECtemp Touch User Manual

Danfoss ECtemp Touch
Installation Guide10
1. Use the arrows in the right
side of the screen to go to
your language, and press to
select it. Then press in the
upper right corner to
conrm.
2. Press the hour numbers and
use the < and > arrows to set
the hour. Press to conrm.
3. Press the minutes numbers
and use the < and > arrows
to set the minutes. Press
to conrm. Press again to
go to the SET DATE screen.
4. Press the day, month and
year respectively and set the
date using the < and >
arrows and pressing to
conrm. When the date is
correct, press to conrm
on the SET DATE screen.

Danfoss ECtemp Touch Specifications

General

Temperature sensor	Yes
Control type	Touch
Product color	White
Memory function	-
International Protection (IP) code	IP21
Voltage	220 - 240 V
Power source	AC
Temperature control range	5 - 45 °C

Weight and Dimensions

Depth	24 mm
Package depth	140 mm
Package width	95 mm
Package height	85 mm
Package weight	24 g
