Danfoss ERC 112D VSC User Manual

Type
I-Pack
Qty. Code no.
Light-sensors
S3, 1000 mm, 3-pole 108 080G3311
S3, 2000 mm, 3-pole 108 080G3313
S3, 3000 mm, 3-pole 108 080G3315
Cable, variable speed compressor
S4, 3500 mm, 3-pole 81 080G3397
Magnetic door sensor
di, 1000 mm, 3-pole 81 080G3320
di, 2000 mm, 3-pole 81 080G3322
di, 3000 mm, 3-pole 81 080G3324
Cable door sensor
di, 1000 mm, 3-pole 108 080G3340
di, 2000 mm, 3-pole 108 080G3341
di, 3000 mm, 3-pole 108 080G3342
di, 4000 mm, 3-pole 81 080G3343
Motion sensor
S3/di, 3000 mm, 3-pole 27 080G3392
Clips
Black (2 needed per controller) 54 080G3308
Programming
OEM Docking station, production
line
1 080G9701
Gateway incl USB Cable, R&D 1 080G9711
Programming key EKA183A 1 080G9740
Power plug *
6-pole with screw 54 080G3357
* The connectors are rated for 28 Amps max.
Sx (di)= connector position.
Inputs are configurable.
Type
I-Pack
Qty. Code no.
ERC 112D VSC, Blue LED, with
buzzer
27 080G3414
Temperature sensors
-40 – 80 °C, PVC Standard, NTC 5 K
S1, 470 mm, 3-pole
120
077F8751
S1, 1000 mm, 3-pole
120
077F8757
S1, 1500 mm, 3-pole
120
077F8761
S1, 2000 mm, 3-pole
120
077F8765
S1, 2200 mm, 3-pole
120
077F8767
S1, 3000 mm, 3-pole
60
077F8769
S1, 3500 mm, 3-pole
60
077F8723
S1, 6000 mm, 3-pole
27
080G2019
-40 – 120 °C, TPE precision NTC 5 K, Santroprene
S1, 1500 mm, 3-pole
120
077F8726
S1, 2000 mm, 3-pole
120
077F8727
-20 – 200 °C, Silicone rubber cable, NTC 100 K
S1/S3, 2000 mm, 3-pole 108 080G2043
-40 – 80 °C, PVC Standard, NTC 5 K
S2, 1000 mm, 2-pole
120
077F8786
S2, 1500 mm, 2-pole
120
077F8790
S2, 2000 mm, 2-pole
120
077F8794
S2, 3000 mm, 2-pole
60
077F8798
S2, 6000 mm, 2-pole
27
080G2029
S3, 1000 mm, 3-pole 120 077F8756
S3, 1500 mm, 3-pole 120 077F8760
S3, 2200 mm, 3-pole 120 077F8766
S3, 3000 mm, 3-pole 60 077F8768
S3, 6000 mm, 3-pole 27 080G2039
Code numbers
Note: For more information about temperature sensor
types and connectors, please refer to Danfoss’ technical
brochure "NTC type temperature sensors for ETC & ERC
controllers".
