User manual ERC 113 refrigeration controller
"S1C"
Default Stn
S1 Config/S1C
S2 Config/S2C
S3 Config/S3C
S4 Config/S4C
S5 Config/S5C (remote display)
S6 Config/S6C (remote display)
Available options are:
"Stn": for a standard temperature sensor NTC 5 K @ 25°C and TPE precision.
"Htn": for a high temperature sensor NTC 100 K @ 25°C.
"Pt1": for a temperature sensor Pt1000 ohm @ 0°C (only "S4").
"Ldr": for a light sensor (values given in Luminens).
"dig": for a digital sensor with simple ON/OFF indication
(motion, magnet, switch, buttom).
"S2C"
Default Stn
"S3C"
Default Stn
"S4C"
Default Stn
"S5C"
Default Stn
"S6C"
Default Stn
"S1A"
Default SCo
S1 Application/S1A
S2 Application/S2A
S3 Application/S3A
S4 Application/S4A
S5 Application/S5A
S6 Application/S6A
Available options are:
"nC": not connected.
"SCo": temperature control.
"EuA": evaporator temperature.
"Con": condenser temperature (Condenser cleaning).
"AuS": only for showing temperature on display.
"Ldr": light sensor, Luminens.
"ECo": external input to control ECO mode.
"doC": door contact, contact closed when door closed.
"doo": door contact, contact open when door closed.
"Pir": motion sensor (only "S3").
"bt5": button 5 (only "S4").
"rsp": remote spindle (only "S3").
"S2A"
Default nC
"S3A"
Default nC
"S4A"
Default nC
"S5A"
Default nC
"S6A"
Default nC
"diC"
Default non
DI Config
This is the digital input used for a digital sensor or bus communications.
"non": not used.
"doC": door contact, contact closed when door closed.
"doo": door contact, contact open when door closed.
"ECo": external input to control ECO mode.
"Pir": motion sensor. Passive infrared.
"o1C"
Default CoP
D01 Config
"CoP": direct compressor control.
"PiC": pilot Relay (no zero cross) – if using pilot relay to control a
compressor, this option must be used instead of "CoP".
"HEt": heating application, inverse output.
"PiH": pilot heat relay (no zero cross).
18
DKRCC.ES.RL0.F5.02 Produced by Danfoss A/S (ADAP-KOOL®) | 2016-07
