Danfoss ERC 211 Installation Guide

| 6 DKRCE.PI.RL0.F6.MLInstruction sheet | ERC 211
3 - Quick Configuration at Power Up
y STEP 1: Power on
y STEP 2: Select the quick configuration menu
Within 30 seconds of power on, press “<” BACK for 3 seconds.
The main switch “r12” is automatically set to OFF.
y STEP 3: Select pre-installed application “o61”
The display automatically shows the application selection parameter “o61”.
Press SET to select the pre-installed application.
The display shows the default value (eg. “AP0” flashing).
Choose the application type by pressing UP/DOWN and press SET to confirm.
The controller presets parameter values according to the selected application and does not hide relevant parameters.
Tip: you can easily move from AP0 to AP5, and thus select the simplified list of parameters, by pressing the UP key
(circular list).
App Description
App 0 None (no preset application)
App 1 Medium temperature (4 – 20 °C), without defrost
App 2 Medium temperature (2 – 6 °C), with timed natural defrost
App 3 Medium temperature (2 – 6 °C), with natural defrost stop on air temperature
App 4 Heating Thermostat (20 – 60 °C)
App 5 None (no preset application) with simplified parameter list
ENGLISH

Danfoss ERC 211 Specifications

General

Type	Electronic Room Controller
Supply Voltage	24 V AC/DC
Relay Outputs	3
Sensor Inputs	2
Application	Refrigeration
Temperature Sensor Type	NTC
Mounting	Panel
