Danfoss ERC 213 Installation Guide

| 6 DKRCE.PI.RL0.G7.ML
Installation Guide | ERC 213
3 - Quick Configuration at Power Up
y STEP 1: Power on
y STEP 2: Select the quick configuration menu
Within 30 seconds of power on, press “<” BACK for 3 seconds.
The main switch “r12” is automatically set to OFF.
y STEP 3: Select pre-installed application “o61”
The display automatically shows the application selection parameter “o61”.
Press SET to select the pre-installed application.
The display shows the default value (eg. “AP0” flashing).
Choose the application type by pressing UP/DOWN and press SET to confirm.
The controller presets parameter values according to the selected application and does not hide relevant parameters.
Tip: you can easily move from AP0 to AP6, and thus select the simplified list of parameters, by pressing the UP key
(circular list).
App Description
App 0 None (no preset application)
App 1 Medium temperature ventilated refrigeration units (2 – 6 °C), with timed natural defrost
App 2 Medium temperature ventilated refrigeration units (0 – 4 °C), with timed electrical defrost
App 3 Low temperature ventilated refrigeration units (-26 – -20 °C), with timed electrical defrost
App 4 Medium temperature ventilated refrigeration units (0 – 4 °C), with electrical defrost (by temperature)
App 5 Low temperature ventilated refrigeration units (-26 – -20 °C), with electrical defrost (by temperature)
App 6 None (no preset application) with simplified parameter list
ENGLISH

Danfoss ERC 213 Specifications

General

Supply Voltage	230 V AC
Dimensions	75 x 33 x 85 mm
Digital Inputs	2
Enclosure Rating	IP20
Input Voltage	230 V AC
Housing Material	Plastic
Application	Refrigeration
Storage Temperature	-20 - 70 °C
Relative Humidity	20% to 80% non-condensing
Protection Class	Class II
Weight	0.2 kg
Operating Temperature	-10°C to +50°C
Power Consumption	3 W
