Danfoss EtherNet/IP Midi Drive FC 280 User Manual

12-03 Default Gateway
Range: Function:
0* [0 -
4294967295]
Congure the IP default gateway of the
option. Read-only, if parameter 12-00 IP
Address Assignment is set to DHCP or
BOOTP. In a non-routed network, this
address is set to the IP address of the IO
Device.
12-04 DHCP Server
Range: Function:
0* [0 - 2147483647 ] Read-only. Show the IP address of the
found DHCP or BOOTP server.
12-05 Lease Expires
Range: Function:
0* [0 - 4294967295] Read-only. Show the lease time left for
the current DHCP-assigned IP address.
12-06 Name Servers
Range: Function:
0* [0 - 4294967295] IP addresses of domain name servers. Can
be automatically assigned when using
DHCP.
12-07 Domain Name
Range: Function:
0 [1 - 48] Domain name of the attached network. Can be
automatically assigned when using DHCP network.
12-08 Host Name
Range: Function:
0* [0 - 48 ] Logical (given) name of option.
NOTICE
The display of the frequency converter only
shows the rst 19 characters, but the
remaining characters are stored in the
frequency converter. If hardware switches
are dierent from all ON or all OFF, the
switches have priority.
12-09 Physical Address
Range: Function:
0* [0 - 17] Read-only. Show the physical (MAC) address of the
option.
5.2.2 12-1* Ethernet Link Parameters
Apply to the whole parameter group.
Index [0] is used for port 1, and index [1] is used for port
2.
12-10 Link Status
Option: Function:
Read-only. Show the link status of the Ethernet
ports.
[0] * No Link
[1] Link
12-11 Link Duration
Range: Function:
Size related* [ 0 - 0] Read-only. Show the duration of the
present link on each port in dd:hh:mm:ss.
12-12 Auto Negotiation
Option: Function:
Congure auto negotiation of Ethernet link
parameters, for each port: ON or OFF.
[0] O Link Speed and Link Duplex can be congured in
parameter 12-13 Link Speed and parameter 12-14 Link
Duplex.
[1] * On
12-13 Link Speed
Option: Function:
Force the link speed for each port in 10 Mbps or
100 Mbps. If parameter 12-12 Auto Negotiation is
set to [1] On, this parameter is read-only and
shows the actual link speed. If no link is present,
None is shown.
[0] * None
[1] 10 Mbps
[2] 100
Mbps
NOTICE
In POWERLINK, this parameter is locked to 100 Mbs.
12-14 Link Duplex
Option: Function:
NOTICE
In POWERLINK, this parameter is locked
to half duplex.
Force the duplex for each port to full or half
duplex. If parameter 12-12 Auto Negotiation is
set to [1] On, this parameter is read-only.
[0] Half Duplex
[1] Full Duplex
Parameters EtherNet/IP
26 Danfoss A/S © 06/2016 All rights reserved. MG07H102
