Danfoss EtherNet/IP Midi Drive FC 280 User Manual

Attribute Access rule Name Data type Description of attribute
Parameter in frequency
converter
1 Get Status DWORD Interface status –
2 Get Conguration capability DWORD Interface capability ags –
3 Get/Set Conguration control DWORD Interface control ags –
4 Get
Physical link object STRUCT of: Path to physical link object –
Path size Uint Size of path –
Path Padded EPATH
Logical segments
identifying the physical link
object
–
5 Get/Set
Interface conguration STRUCT of:
TCP/IP network interface
conguration
–
IP address UDINT The device IP address 12-01
Network mask UDINT The device network mask 12-02
Gateway address UDINT Default gateway address 12-03
Name server UDINT Primary name server 12-06 [0]
Name server 2 UDINT Secondary name server 12-06 [1]
Domain name STRING Default domain name 12-07
6 Get/Set Host name STRING Host name 12-08
Table 7.10 Instance Attributes-Class ID 0xF5 Interface Object
3 instances of the link object are implemented:
•
Instances 1 and 2 relate to the physical ports 1 and 2 of the option.
•
Instance 3 relates to the internal interface of the option after the built-in switch.
Attribute
Access
rule
Name Data type Description of attribute
Parameter in frequency
converter
1 Get Interface speed UDINT
Interface speed in Mbps (that is 0, 10, 100,
1000, and so on).
12-13
2 Get Interface ags DWORD Interface status ags. –
3 Get Physical address
ARRAY of 6
USINTs
MAC layer address. 12-09
4 Get
Interface counters STRUCT of – –
In octets UDINT Octets received on the interface. 12-98 [0]
In Ucast packets UDINT Unicast packets received on the interface 12-98 [1]
In NUcast packets UDINT
Non-unicast packets received on the
interface.
12-98 [2]
In discards UDINT
Inbound packets received on the interface
but discarded.
12-98 [3]
In errors UDINT
Inbound packets that contain errors (does
not include In Discards).
12-98 [4]
In unknown
protos
UDINT Inbound packets with unknown protocol. 12-98 [5]
Out octets UDINT Octets sent on the interface 12-98 [6]
Out Ucast packets UDINT Unicast packets sent on the interface. 12-98 [7]
Out NUcast
packets
UDINT Non-unicast packets sent on the interface. 12-98 [8]
Out discards UDINT Outbound packets discarded. 12-98 [9]
Out errors UDINT Outbound packets that contain errors. 12-98 [10]
Appendix Programming Guide
MG07H102 Danfoss A/S © 06/2016 All rights reserved. 41
7 7
