Danfoss FC 302 - How to Read this Instruction Manual

X2.1–X2.4 Motor Connectors M23 (in M25)
Female
General ratings
•
Pins 1, 2, 3, and 4: 480 V AC, maximum 15 A.
•
Pins C and D: 30 V DC, maximum 3 A.
•
Tightening torque: 1.5–2.0 Nm (13.3–17.7 in-lb).
Pin Label Connected to frequency
converter wiring schematic
Minimum
wire [mm
2
(AWG)]
1 U 96 (U) 2.5 (14)
3 V 97 (V) 2.5 (14)
4 W 98 (W) 2.5 (14)
2 PE 99 (PE) 2.5 (14)
Table 4.3 Wire/Connector Assignment for Plug X2
Mating part: Motor X2 (male)
Phoenix ordering number: KCX-K0341/XX,XX
Maximum cable length: 7.0 m (23 ft)
2 Motor Connection Variant (134N3195)
To meet the protection rating, always keep blind plugs
installed.
Label Connected to frequency converter wiring schematic
X2.1-B 53
X2.2-A 50
X2.1-A and
X2.2-B
Connected to a common terminal
X2.1-C and
X2.2-C
Connected to an open terminal available in the
frequency converter
X2.1-D and
X2.2-D
Connected to an open terminal available in the
frequency converter
Table 4.4 2 Motor Connection
4 Motor Connection Variant (134N3196)
Label Connected to frequency converter wiring schematic
X2.1-B 53
X2.4-A 50
X2.1-A and
X2.2-B
Connected via an internal terminal
X2.2-A and
X2.3-B
Connected via an internal terminal
X2.3-A and
X2.4-B
Connected via an internal terminal
Table 4.5 4 Motor Connection
X51 PROFIBUS M12 Male, X52 PROFIBUS M12
Female
General ratings
•
30 V DC, maximum 1 A.
•
Tightening torque: 0.2–0.3 Nm (1.8–2.7 in-lb)
Label Connected to frequency converter PROFIBUS
connector
15 V DC 67
2– 63
30 V DC 66
4– 62
Table 4.6 PROFIBUS Connection
Mating part: PROFIBUS X52 and X51 (female/male)
Phoenix ordering number: SAC-2P-MSB/ XX,XX-910/FSB SCO CT
X11–X14 I/O Connector Box (134N3195–
134N3196)
Phoenix sensor/actuator box - SACB-4/4-L-0,57HPUR CDA -
1531426.
Tightening torque sensor/actuator cable: 0.4 Nm (3.5 in-lb).
Label Wire Connected to frequency converter
wiring schematic
X11-X14 1
Brown 12
+24 V OutX11-X14 2
X11-X14 3 Blue 20 COM D IN
X14-4 Gray 33 D IN
X13-4 Yellow 29 D IN/OUT
X12-4 Green 19 D IN
X11-4 White 18 D IN
Table 4.7 Connector Box (134N3195–134N3196)
X11–X14 I/O Connector Box (134N8410)
Phoenix sensor/actuator box - SACB-4/4-L-0,57HPUR CDA -
1531426.
Tightening torque sensor/actuator cable: 0.4 Nm (3.5 in-lb)
Label Wire Connected to wiring schematic
X11-X14 1
Brown
Connected to
frequency
converter wiring
schematic
12
+24 V Out
X11-X14 2
X11-X14 3 Blue 20 COM D IN
X14-4 Gray
Connected to C-
option, MCO 305
wiring schematic
X57-4 –
X13-4 Yellow X57-3 –
X12-4 Green X57-2 –
X11-4 White X57-1 –
Table 4.8 Connector Box (134N8410)
Installation Instructions VLT® AutomationDrive FC 302 with Connectors
MI04G402 Danfoss A/S © 11/2015 All rights reserved. 3
