FCM 300 Series
MG.03.B6.02 - VLT is a registered Danfoss trademark12
Ordering form FCM 300 Series
Mounting vs. and flange size (char. nos. 24-29)
(B03) B3 Foot 0 0 0
(B05) B5 Flange flange size
(B35) Foot & flange flange size
(B14) Face flange size
(B34) Foot & face flange size
Tick off as appropriate and select flange size from
the table on page 11.
Inverter box position (char. no. 30)
(T) Top
(R) Right side
(L) Left side
Tick off as appropriate.
Inverter box position is seen from drive end.
(See drawing on page 11).
Drain hole position (char. nos. 31-32)
(00) None
(D1) Between feet
(D2) Opposite feet
(D3) Vertical drive end
(D4) Vertical non-drive end
(D5) 90
° °
° °
° right of feet
(D6) 90
° °
° °
° left of feet
Tick off as appropriate.
(See drawing on page 11).
Other options (contact Danfoss for code)
Number of FCM 300 Series ordered
Ordering form FCM 300 Series
FCM type (character nos. 1-6) FCM
Select the required FCM type from the product
range on the previous page and fill in the squares.
Application range (char. no. 7)
(P) Process
Mains voltage (char. nos. 8-9)
(T4) 3-phase 380-480 V AC
Tick off as appropriate.
Inverter vs. (char. nos. 10-11)
(ST) Standard
(SP) PROFIBUS
Tick off as appropriate.
Enclosure (char. no. 12-14)
(S55) IP55
(S56) IP56
(S66) IP66
RFI filter (char. nos. 15-16)
(R1) W/ integrated filter, class A1
(R2) W/integrated filter, class B1
Tick off as appropriate.
Frame size (char. nos. 17-21)
Fill in the squares with the appropriate value from
column 2 and 3 in the table on page 11.
Polarity (char. no. 22)
(4) 4 poles
(2) 2 poles
Tick off as appropriate.
Cooling (char. no. 23)
(1) (IC 411) Shaft mounted fan
(6) (IC 416) Forced ventilation unit
Tick off as appropriate.
Selection of FC motor
Ordered by:
Date:
