Technical data
Mains supply, TT, TN and IT* (L1, L2, L3):
- Supply voltage 380-480 V units ........................................................... 3 x 380/400/415/440/460/480 V ±10%
- Supply frequency................................................................................................................................ 50/60 Hz
- Max. imbalance of supply voltage......................................................................... ±2% of rated supply voltage
- Power factor / cos ϕ ....................................................................................................... max. 0.9/1.0 at rated load
- No. of switching operations on supply input L1, L2, L3 ................................................. approx. 1 time/2 min
See chapter 10, "Special conditions".
*) Not valid for RFI class 1B units
Torque characteristics:
- Starting torque/overload torque ..............................................................................................160 % for 1 min
- Continuous torque ........................................................................................................................see page 84
■ FCM 305-375 for 3 phases, 380-480 V
■ General technical data
FCMFCM
FCMFCM
FCM
305305
305305
305
307307
307307
307
311311
311311
311
315 315
315 315
315
322322
322322
322
330330
330330
330
340340
340340
340
355355
355355
355
375375
375375
375
Motor output
[HP] 0.75 1.0 1.5 2.0 3.0 4.0 5.0 7.5 10.0
[kW] 0.55 0.75 1.1 1.5 2.2 3.0 4.0 5.5 7.5
Motor torque
2 pole [Nm] 1.8 2.4 3.5 4.8 7.0 9.5 12.6 17.5 24.0
4 pole [Nm] 3.5 4.8 7.0 9.6 14.0 19.1 25.4 35.0 48.0
Frame
size [mm] 80 80 90 90 100 100 112 132 132
Weight [kg]111317202628375661
Input current [A]
380 V
2 p 1.4 1.6 2.2 2.8 4.1 5.3 7.0 9.3 13.0
4 p 1.4 1.7 2.5 3.3 4.7 6.4 7.9 11.1 15.3
480 V
2 p 1.2 1.3 1.8 2.3 3.3 4.2 5.6 7.4 10.2
4 p 1.1 1.4 2.0 2.6 3.7 5.1 6.4 8.8 11.9
Power
terminals
[AWG] 10 10 10 10 10 10 10 6 6
[mm
2
] 44444441010
Gland sizes 3XPG16 3XPG16 3XPG16 3XPG16 3XPG16 3XPG16 3XPG16 1XPG21/ 1XPG21/
3XPG16 3XPG16
Max. prefuse
UL
1)
[A] 10 10 10 10 10 15 15 25 25
IEC
1)
[A] 25 25 25 25 25 25 25 25 25
1)
Type gG prefuses must be used. If you want to maintain UL/cUL you must use prefuses of the type
Bussmann KTS-R 500 V or Ferraz Shawmut, type ATMR (max. 30A). The fuses must be placed for protection
in a circuit that is capable of supplying a maximum of 100,000 amps RMS (symmetrical), 500 V maximum.
