Danfoss FCM 300 Series User Manual

FCM 300 Series
15
MG.03.B6.02 - VLT is a registered Danfoss trademark
Control card, analogue inputs:
- No. of programmable analogue voltage inputs .............................................................................................. 1
- Terminal nos. ......................................................................................................................................... X101-2
- Voltage level.................................................................................................................... 0 - 10 V DC (scalable)
- Input resistance, R
i
..................................................................................................................... approx. 10 kΩ
- No. of programmable analogue current inputs.................................................................................................1
- Terminal no. ........................................................................................................................................... X101-1
- Current range .................................................................................................................... 0 - 20 mA (scalable)
- Input resistance, R
i
.....................................................................................................................approx. 300 Ω
- Resolution...................................................................................................................................................9 bit
- Accuracy on input.....................................................................................................Max. error 1% of full scale
- Scanning time ................................................................................................................................... 20 msec.
Control card, digital/pulse and analogue outputs:
- No. of programmable digital and analogue outputs ....................................................................................... 1
- Terminal nos.......................................................................................................................................... X101-9
- Voltage level at digital output/load .................................................................................... 0 - 24 V DC/25 mA
- Current at analoque output ............................................................................................................. 0 - 20 mA
- Maximum load to frame (terminal 8) at analogue output ........................................................... R
LOAD
≤ 500 Ω
- Accuracy of analogue output ............................................................................ Max. error: 1.5% of full scale
- Resolution on analogue output..................................................................................................................8 bit
Control card, RS 485 serial communication:
- Terminal nos. ....................................................................................................................................X100-1, -2
Control characteristics (frequency converter):
- Frequency range............................................................................................................................... 0 - 132 Hz
- Resolution on output frequency............................................................................................................. 0.1 %
- System response time .............................................................................................................. Max. 40 msec.
Technical data
Control card, digital/pulse inputs:
- Number of programmable digital inputs ..........................................................................................................4
- Terminal nos.........................................................................................................................X101-2, -3, -4, -5
- Voltage level ................................................................................................... 0-24 V DC (PNP positive logics)
- Voltage level, logic ´0´ ........................................................................................................................ < 5 V DC
- Voltage level, logic ´1´ ...................................................................................................................... > 10 V DC
- Maximum voltage on input .................................................................................................................28 V DC
- Input resistance, R
i
..................................................................................................................... approx. 2 kΩ
- Scanning time ................................................................................................................................... 20 msec
Control card, pulse input:
- No. of programmable pulse inputs................................................................................................................ 1
- Terminal nos.......................................................................................................................................... X101-3
- Max. frequency on terminal 3, open collector/push pull 24 V ................................................... 8 kHz/70 kHz
- Resolution ................................................................................................................................................10 bit
- Accuracy (0.1-1 kHz), terminal 3...................................................................... Max. error: 0.5% of full scale
- Accuracy (1-12 kHz), terminal 3 ........................................................................ Max. error: 0.1% of full scale
