332 Terminal 2, analogue/digital input
(DIGITAL INPUT 2)
333 Terminal 3, digital input
(DIGITAL INPUT 3)
334 Terminal 4, digital input
(DIGITAL INPUT 4)
335 Terminal 5, digital input
(DIGITAL INPUT 5)
Parameter 332 333 334 335
Digital input on terminal no. 2 3 4 5
Settings:
No function (NO OPERATION) [0] [0] [0] [0]
Reset (RESET) [1] ✭ [1] [1] [1]
Coasting stop, inverse (MOTOR COAST INVERSE) [2] [2] [2] [2]
Reset and coasting stop, inverse (RESET & COAST INV.) [3] [3] [3] [3]
Quick-stop, inverse (QUICK STOP INVERSE) [4] [4] [4] [4]
DC-braking, inverse (DC-BRAKE INVERSE) [5] [5] [5] [5]
Stop inverse (STOP INVERSE) [6] [6] [6] [6]
Start (START) [7] [7] ✭ [7] [7]
Latched start (LATCHED START) [8] [8] [8] [8]
Reversing (REVERSING) [9] [9] [9] [9]
Start reversing (START REVERSING) [10] [10] [10] [10]
Start clockwise, on (ENABLE FORWARD) [11] [11] [11] [11]
Start counter-clockwise, on (ENABLE REVERSE) [12] [12] [12] [12]
Jog (JOGGING) [13] [13] [13] ✭ [13]
Freeze reference (FREEZE REFERENCE) [14] [14] [14] [14]
Freeze output (FREEZE OUTPUT) [15] [15] [15] [15]
Speed up (SPEED UP) [16] [16] [16] [16]
Speed down (SPEED DOWN) [17] [17] [17] [17]
Selection of Setup (SETUP SELECT) [18] [18] [18] [18]
Catch-up (CATCH UP) [19] [19] [19] [19]
Slow-down (SLOW DOWN) [20] [20] [20] [20]
Preset reference (PRESET REF.) [21] [21] [21] [21]
Preset reference, on (PRESET REF. ON) [22] [22] [22] [22]
Precise stop, inverse (PRECISE STOP) [23]
Pulse reference (PULSE REFERENCE) [24]
Pulse feedback (PULSE FEEDBACK) [25]
Analogue reference (REFERENCE) ✭ [30]
Analogue feedback (FEEDBACK) [31]
Reset and start (RESET AND START) [32] [32] [32] [32]
Function:
In parameters 332-335 it is possible to choose
between the different possible functions related to the
inputs on terminals 2-5. The function options are
shown in the table below.
✭ = factory setting. ( ) = parameter window text. [ ] = value for use in communication via serial communication port
Description of choice:
No functionNo function
No functionNo function
No function is selected if the FC motor is not to react
to signals transmitted to the terminal.
Reset Reset
Reset Reset
Reset zeroes the FC motor after an alarm; however,
not all alarms can be reset without disconnecting
from mains.
Coasting stop, inverseCoasting stop, inverse
Coasting stop, inverseCoasting stop, inverse
Coasting stop, inverse is used for making the FC
motor run freely to stop. Logic '0' leads to coasting
stop.
Reset and coasting stop, inverseReset and coasting stop, inverse
Reset and coasting stop, inverseReset and coasting stop, inverse
Reset and coasting stop, inverse, is used for
activating coasting stop at the same time as reset.
Logic ‘0’ leads to coasting stop and reset.
Quick-stop, inverseQuick-stop, inverse
Quick-stop, inverseQuick-stop, inverse
Quick-stop, inverse is used for stopping the motor in
accordance with the quick-stop ramp (set in
parameter 212).
Logic '0' leads to a quick-stop.
