JogJog
JogJog
Jog is used for overriding the output frequency to the
jog frequency set in parameter 213. The ramp time
can be set in parameter 211. Jog is not active if a
stop command has been given (start-disable).
Jog overrides stand-by.
Freeze referenceFreeze reference
Freeze referenceFreeze reference
Freeze reference - freezes the actual reference. The
frozen reference is now the point of enable/condition
for Speed up and Speed down to be used.
If speed up/down is used, the speed change always
follows the normal ramp (parameters 207/208) in the
range 0 - Ref
MAX.
Freeze outputFreeze output
Freeze outputFreeze output
Freeze output - freezes the actual motor frequency
(Hz). The frozen motor frequency is now the point of
enable/condition for Speed up and Speed down to
be used.
Freeze output overrides start/stand-by, slip
compensation and closed loop process control.
If speed up/down is used, the speed change always
follows the normal ramp (parameters 207/208) in the
range 0 - f
M,N
.
Speed upSpeed up
Speed upSpeed up
Speed up
and and
and and
and
Speed downSpeed down
Speed downSpeed down
Speed down are selected if digital
control of the up/down speed is desired (motor
potentiometer). This function is only active if Freeze
reference or Freeze output has been selected.
As long as there is a logic ‘1‘ on the terminal selected
for speed up, the reference or the output frequency
will increase.
As long as there is a logic ‘1‘ on the terminal selected
for speed down, the reference or the output
frequency will be reduced.
Pulses (logic ‘1‘ minimum high for 20 ms and a
minimum pause of 20 ms) will lead to a change of
speed of 0.1% (reference) or 0.1 Hz (output
frequency).
Example:
Terminal Freeze ref./
2-5 2-5 Freeze output
No speed change 0 0 1
Speed down 0 1 1
Speed up 1 0 1
Speed down 1 1 1
DC braking, inverseDC braking, inverse
DC braking, inverseDC braking, inverse
DC braking, inverse is used for stopping the motor by
energizing it with a DC voltage for a given time, see
parameters 126-127.
Please note that this function is only active if the
settings of parameters 126-127 is different from 0.
Logic '0' leads to DC braking.
Stop inverseStop inverse
Stop inverseStop inverse
Stop inverse is activated by interrupting the voltage to
the terminal. This means that if the terminal has no
voltage, the motor cannot run. The stop will be
effected in accordance with the selected ramp
(parameters 207/208).
None of the above-mentioned stop
commands are to be used
as disconnection switch in connection with
repairs. Cut mains instead.
StartStart
StartStart
Start, is selected if a start/stop command is desired.
Logic '1' = start, logic '0' = stop (stand-by).
Latched start Latched start
Latched start Latched start
Latched start - if a pulse is applied for min. 20 ms,
the motor will start, provided no stop command. The
motor stops if Stop inverse is activated briefly.
ReversingReversing
ReversingReversing
Reversing is used for changing the direction of
rotation of the motor shaft. Logic "0" will not lead to
reversing. Logic "1" will lead to reversing. The
reversing signal only changes the direction of rotation;
it does not activate the start function.
Should not be used with Process, closed loop mode.
Start reversingStart reversing
Start reversingStart reversing
Start reversing, is used for start/stop and for reversing
with the same signal. No start signal is allowed at the
same time. Acts as latch start reversing, provided
latch start has been chosen for another terminal.
Should not be used with Process, closed loop mode.
Start clockwiseStart clockwise
Start clockwiseStart clockwise
Start clockwise,
on on
on on
on is used if the motor shaft is only to
be able to rotate clockwise when starting.
Should not be used with Process, closed loop mode.
Start counterStart counter
Start counterStart counter
Start counter
-clockwise-clockwise
-clockwise-clockwise
-clockwise,
on on
on on
on is used if the motor shaft
is to be able to rotate counter-clockwise when
started.
Should not be used with Process, closed loop mode.
Inputs and Outputs
✭ = factory setting. ( ) = parameter window text. [ ] = value for use in communication via serial communication port
