✭ = factory setting. ( ) = parameter window text. [ ] = value for use in communication via serial communication port
339 Terminal 2, max. scaling
(AI 2 SCALE HIGH)
Settings:
0.0 - 10.0 V [0 - 100]
★ 10.0 V [100]
Function:
This parameter is used for setting the signal value that
corresponds to the maximum reference value set in
parameter 205.
Description of choice:
Set the desired voltage value.
340 Terminal 9, output functions (OUTPUT FUNC.)
Settings:
✭ No function (NO OPERATION) [0]
Ready signal (UNIT READY) [1]
Enable, no warning (ENABLE/NO WARNING) [2]
Running (MOTOR RUNNING) [3]
Running, no warning (RUNNING NO WARNING) [4]
Running on reference, no warning (RUNNING ON REFERENCE) [5]
Fault (FAULT) [6]
Fault or warning (FAULT OR WARNING) [7]
Current limit (CURRENT LIMIT) [8]
Thermal warning (THERMAL WARNING) [9]
Reversing (REVERSE) [10]
Off 123 (OFF 123 RELAY) [11]
Actual frequency 0-20 mA (0-FMAX = 0-20 mA) [12]
Actual frequency 4-20 mA (0-FMAX = 4-20 mA) [13]
Reference
MIN
- reference
MAX
: 0-20 mA (REF MIN-MAX =0-20 mA) [14]
Reference
MIN
- reference
MAX
: 4-20 mA (REF MIN-MAX =4-20 mA) [15]
Feedback
MIN
- feedback
MAX
: 0-20 mA (FB MIN-MAX =0-20 mA) [16]
Feedback
MIN
- feedback
MAX
: 4-20 mA (FB MIN-MAX =4-20 mA) [17]
Actual current 0-20 mA (0-IMAX = 0-20 mA) [18]
Actual current 4-20 mA (0-IMAX = 4-20 mA) [19]
Mechanical brake (MECHANICAL BRAKE) [20]
Function:
This output can act both as a digital and an
analogue output. If used as a digital output (data
value [0]-[20]), a 24 V DC signal is transmitted; if
used as an analogue output either a 0-20 mA
signal, or a 4-20 mA signal output.
Description of choice:
Unit Ready signal, the FC motor is ready for use.
Enable/no warning, the FC motor is ready for use; no
start or stop command has been given (start/disable).
No warning.
Motor Running, the output frequency is higher than
0.1 Hz. A start command has been given.
Running no warning, the output frequency is higher
than 0.1 Hz. A start command has been given. No
warning.
Running on reference, no warning, speed according
to reference. No warning.
Fault, output is activated by alarm.
Fault or warning, the output is activated by alarm or
warning.
Current limit, the current limit in parameter 221 has
been exceeded.
Thermal warning, above the temperature limit in the
frequency converter.
Reverse. Logic '1' = relay activated, 24 V DC on the
output when the direction of rotation of the motor is
clockwise. Logic '0' = relay not activated, no signal
on the output, when the direction of rotation of the
motor is counter-clockwise.
Inputs and outputs
