Off 123 relay, if Profidrive [0] has been selected in
parameter 512, the output is activated. If either OFF1,
OFF2 or OFF3 (bit in the control word) is logic '1'.
0-f
MAX
(parameter 202) ⇒ 0-20 mA and
0-f
MAX
(parameter 202) ⇒ 4-20 mA
Reference
MIN
- Reference
MAX
: 0-20 mA and
Reference
MIN
- Reference
MAX
: 4-20 mA
Feedback
LOW
- Feedback
HIGH
: 0-20 mA and
Feedback
LOW
- Feedback
HIGH
: 4-20 mA
0-I
VLT, MAX
⇒ 0-20 mA and
0-I
VLT, MAX
⇒ 4-20 mA
Mechanical brake, enables control of an optional
external mechanical brake (see also parameter 138
and 139).
Inputs and Outputs
