Danfoss iC7 Series User Manual

P 9.3.3 T2 Analog Input Value
Description: Shows the actual value of the terminal.
Default Value: NA
Parameter Type: Range (-20 — 20)
Parameter Number: 1620
Unit: -
Data Type: REAL
Access Type: Read Only
P 9.3.4 T3 Analog Input Value
Description: Shows the actual value of the terminal.
Default Value: NA
Parameter Type: Range (-20 — 20)
Parameter Number: 1621
Unit: -
Data Type: REAL
Access Type: Read Only
P 9.3.5 T4 Analog Output Value
Description: Shows the actual value of the terminal.
Default Value: NA
Parameter Type: Range (0 — 20)
Parameter Number: 1622
Unit: -
Data Type: REAL
Access Type: Read Only
P 9.3.6 T2 Temperature Value
Description: Shows the measured temperature of the terminal.
Default Value: NA
Parameter Type: Range (-1000 — 1000)
Parameter Number: 4966
Unit: °C
Data Type: REAL
Access Type: Read Only
P 9.3.7 T3 Temperature Value
Description: Shows the measured temperature of the terminal.
Default Value: NA
Parameter Type: Range (-1000 — 1000)
Parameter Number: 4967
Unit: °C
Data Type: REAL
Access Type: Read Only
7.6.2 Analog Inputs/Outputs (Menu Index 9.4)
7.6.2.1 Input T2 (Menu Index 9.4.1)
P 9.4.1.1 T2 Terminal Mode
Description: Select the mode for the terminal.
Default Value: 0 [Inactive]
Parameter Type: Selection
Parameter Number: 4915
Unit: -
Data Type: UINT
Access Type: Read/Write
The following are the selections for the parameter
Selection number
Selection name
0
Inactive
6
Analog Input
7
Temperature input
P 9.4.1.2 T2 Terminal Type
Description: Select the type of the terminal. If voltage is selected, the unit is V. If current is selected, the unit is mA.
Default Value: 1 [Voltage]
Parameter Type: Selection
Parameter Number: 4916
Unit: -
Data Type: UINT
Access Type: Read/Write
The following are the selections for the parameter
AQ390830267692en-000601 / 136R0273 | 53Danfoss A/S © 2023.06
General Purpose I/O Installation
and Configuration
Functional Extension Options
Operating Guide
