Danfoss IPS 8 Technical Data, Installation And Use

User Guide | Intelligent Purging System (IPS 8) for Ammonia - Technical data, installation and use
© Danfoss | DCS (ms) | 2020.01
BC306932151284en-000201 | 25
Register Parameter Name Description
User
Level
Min Value Max Value
Default
Value
Unit/
Type
Read/
Write
Modbus
Function
Code
Modbus
Data Type
Persistent
Yes/No
1902 .08 Discharge sensor error
Indicates no signal
from temperature
sensor
0 0 1 0 AUTO R.
Read
only
3 Long No
1902 .09 Suction sensor error
Indicates no signal
from temperature
sensor
0 0 1 0 AUTO R.
Read
only
3 Long No
I/O CONFIGURATION
ANALOG INPUTS
1005 BPL-1/34
Pressure at the R452a
suction line
2 -1.0 34.0 N/A 0-5 V
Read
only
3 Short No
1006 BPH-1/59
Condensing pressure
of R717
2 -1.0 59.0 N/A 0-5 V
Read
only
3 Short No
1007 Dis. Temp
Measured discarge
temperature of
compressor
2 -50.0 170.0 N/A PT1000
Read
only
3 Short No
1008 TempSuction
Measured suction
temperature
2 -50.0 170.0 N/A PT1000
Read
only
3 Short No
1009 NC Temp
Measured non
Condensable gas
temperature
2 -50.0 170.0 N/A PT1000
Read
only
3 Short No
1010 ---------------- Not used N/A 0 100 N/A NO
Read
only
N/A N/A N/A
1011 ---------------- Not used N/A 0 100 N/A NO
Read
only
N/A N/A N/A
1012 ---------------- Not used N/A 0 100 N/A NO
Read
only
N/A N/A N/A
1013 ---------------- Not used N/A 0 100 N/A NO
Read
only
N/A N/A N/A
1014 ---------------- Not used N/A 0 100 N/A NO
Read
only
N/A N/A N/A
DIGITAL INPUTS
1001.08 Status KL1
Compressor status
(KL01)
0: Compressor off
1: Compressor on
2 0 1 1 N.O.
Read
only
3 Short No
1001.09 On/Off
Main switch input
0: Main switch off
1: Main switch on
2 0 1 1 N.O.
Read
only
3 Short No
1001.10 General Alarm General Alarm input 2 0 1 0 N.O.
Read
only
3 Short No
1001.11 LiquidAlarm Liquid Alarm input 2 0 1 0 N.O.
Read
only
3 Short No
1001.12 ---------------- Not used N/A 0 1 N/A N.C.
Read
only
N/A N/A N/A
1001.13 ---------------- Not used N/A 0 1 N/A N.C.
Read
only
N/A N/A N/A
1001.14 ---------------- Not used N/A 0 1 N/A N.C.
Read
only
N/A N/A N/A
1001.15 ---------------- Not used N/A 0 1 N/A N.C.
Read
only
N/A N/A N/A
1001.00 ---------------- Not used N/A 0 1 N/A N.C.
Read
only
N/A N/A N/A
1001.01 ---------------- Not used N/A 0 1 N/A N.C.
Read
only
N/A N/A N/A
1001.02 ---------------- Not used N/A 0 1 N/A N.C.
Read
only
N/A N/A N/A
1001.03 ---------------- Not used N/A 0 1 N/A N.C.
Read
only
N/A N/A N/A
1001.04 ---------------- Not used N/A 0 1 N/A N.C.
Read
only
N/A N/A N/A
1001.05 ---------------- Not used N/A 0 1 N/A N.C.
Read
only
N/A N/A N/A
1001.06 ---------------- Not used N/A 0 1 N/A N.C.
Read
only
N/A N/A N/A
1001.07 ---------------- Not used N/A 0 1 N/A N.C.
Read
only
N/A N/A N/A
1002.08 ---------------- Not used N/A 0 1 N/A N.C.
Read
only
N/A N/A N/A
1002.09 ---------------- Not used N/A 0 1 N/A N.C.
Read
only
N/A N/A N/A
