Danfoss IPS 8 Technical Data, Installation And Use

User Guide | Intelligent Purging System (IPS 8) for Ammonia - Technical data, installation and use
4 | BC306932151284en-000201
© Danfoss | DCS (ms) | 2020.01
Ordering
Unit
Code number
Danfoss Intelligent Purging System IPS 8 unit 084H5001
Accessories/Spare parts Accessory Spare part Code
Flange blind blank incl Bolts, nuts and Gaskets* x 084H5053
SV3 Float Valve x 027B2023
ICF 15-4 solenoid, DIN Butt weld 15mm ½ inch x 027L4543
ICF 15-4 solenoid, ANSI Socket weld 15mm ½ inch x 027L4538
ICF 15-4 solenoid, ANSI Butt weld 15mm ½ inch x 027L4602
Welding Flange incl Bolts, nuts and Gaskets x 084H5055
Purger solenoid kit (Armature, tube, Sealing, Orifice, Filter insert) x 084H5051
Solenoid coil, 220 – 230V, 50 HZ for AKV x 018F6801
Solenoid coil, 24V DC for AKV x x 018F6757
PSU, 24V DC - optional for powering purge points x x 080Z0055
Restrictor, purge line x 084H5054
Compressor Cranck case heater x 084H5058
Condenser coil assy incl screws x 084H5059
Fan motor for condenser Incl fan grid and screws x 084H5060
Extraction Fan x 084H5056
Air grid with filter (2 pieces) x 084H5057
Pre-programmed MCX 15 x 084H5052
Pressure transmitter evaporator, soldered (AKS 32R) x 060G3552
Compressor including Start relay box and Start and Run Capacitor x 123F2126
Compressor Hi-temp sensor x 084N2003
Expansion valve, R452A x 068U3881
Sight glass x 014-0191
Pressure transmitter - R717, Threaded, AKS2050 x 060G5750
Thermostat for crankcase heater control x 060L111166
Temperature sensor - R717, AKS 21M x 084N2003
Pressure switch for Fan x Contact Danfoss
Pressure safety switch x Contact Danfoss
* For closing system flange during system pressure testing
Technical data
Supply voltage 230V AC, 1ph, 50Hz
Current 5.7 A (max. 6.5 A)
Power consumption max. 1.3 kW
Short-circuit current rating Icc 10kA
Temperature range ambient -10 °C to +43 °C (14 °F to 109 °F)
Temperature range transport/storage -30 °C to +60 °C (-22 °F to 140 °F)
Enclosure IP55
Weight max. 100 kg (221 lbs)
Dimensions (LxWxH) 1051 x 441 x 703 mm (41.4 x 17.4 x 27.7 inches)
Purger refrigerant R452A 900 gram (31.7 oz)
Max. operating pressure (PS) R452A 28 bar (406 psi)
System refrigerant R717
Min. operating pressure R717 6.5 bar (94 psi)
Max. operating pressure R717 40 bar (580 psi)
Operating temperature R717 -40 °C to +60 °C (-40 °F to 140 °F)
Note:
All Spare part items are parts already built into
the IPS 8. All accessories are not.
