Marking
Installation
living connect® is supplied with adapters for
Danfoss RA valves and valves with M30X1.5
(K) connections (code no. 014G0002), two al-
kaline AA batteries and a 2 mm Allen key.
Inserting the batteries
Remove the battery cover and insert the two
batteries. Ensure that the batteries are cor-
rectly inserted. A capital "M" must flash on the
display before installation.
RA K
▪
Start by mounting the adapter.
▪
Tighten the RA adapter using the Allen
key. Tighten the K adapter by hand (max.
5 Nm).
▪
Screw the thermostat onto the adapter
and hand-tighten (max. 5 Nm).
2 mm Allen key
▪
Press and hold for approx. 3 seconds
to fix the thermostat.
Data Sheet living connect®, Z-Wave Certified Electronic Radiator Thermostat
Danfoss Heating Solutions VDHMB202 © Danfoss 09/2011 3
